Confirm the structure of your synthesized and/or purified product

- Is my product what I expect to be?

- Does my product have any impurities?

Our instruments

Nottingham Analytical has access to NMR spectrometers ranging from 400 MHZ to 800 MHz with various capabilities that are listed below.

• Bruker AV(III)400HD - chmnmr400hd equipped with a 60 position autosampler and a 5 mm autotune broadband prodigy cryoprobe with z gradients, automated gradient shimming capability.
• Bruker AV400 - chmnmr400a equipped with a 60 position autosampler and a 5 mm autotune broadband probe with z gradients, automated gradient shimming capability.
• Bruker AV(III)400 - chmnmr400b equipped with a 60 position autosampler and a 5mm autotune broadband probe with z gradients, automated gradient shimming capability.
• Bruker AV(III)500 chmnmr500 equipped 60 position autosampler, with a 5mm dual 1H/13C cryoprobe with z gradients, automated gradient shimming capability.
• Bruker AV(III)400HD - cnlnmr400o equipped with a 60 position autosampler and a 5 mm autotune broadband probe with z gradients, automated gradient shimming capability.
• Bruker AV(III)400HD - cnlnmr400r equipped with a 24 position autosampler and a 5 mm autotune broadband probe with z gradients, automated gradient shimming capability.
• Bruker AV(III)500HD - cnlnmr500 equipped with a 24 position autosampler and a 5 mm autotune broadband prodigy cryoprobe with z gradients, automated gradient shimming capability.
• Bruker AV(III)600 equipped with 5mm TXI and BBFO+ probes with z field gradients, full automation including high throughput autosampler. Solid state capability: 2.5mm HYX and 1.3mm HX probes.
• Bruker Neo800 equipped with 5mm QCI and 1.7mm TXI cryoprobes with z filed gradients. Fitted with 60 position autosampler. Solid state capability: 1.3mm HX, 3.2mm HCN and 2x 3.2mm (high and low gamma) probes.

 Get in touch now!
