GGITLM is the Institute's TLM based time domain simulation code, distributed under an open source license. The general purpose code is capable of predicting time domain which may be subsequently transformed into the frequency domain.

Features include:

  • Frequency domain material models including an impedance boundary representation of thin layer materials (metals, CFC, metallic mesh)
  • Multi-conductor cable model including shielded cables and frequency dependent properties
  • Large scale capability-parallel via MPI
MP180613AH1_141

TLM Time Domain
Modelling Code
(ggiTLM)

Simulation of plane wave illumination of an aircraft showing time evolving E field on a plane and magnitude of surface current density.



Contact

For enquiries relating to the TLM, please contact the ggiTLM research group.

Obtaining ggiTLM

To obtain access to the TLM time domain modelling code, please click here.
